S-LOK Bite Type Tube Fittings (DIN 2353)

Features:

  • S-LOK bite type fittings are designed in accordance with DIN 2353.
  • S-LOK bite type fitting is consists of a body, a progressive ring (sleeve) and a nut.
  • They are designed and manufactured to produce a strong, reliable, leak-free joint upon proper assembly.

Standard Material Specifications:

  • Steel Fittings: Materials see DIN3859.
  • Stainless Steel Fitting: X5CrNiMo 17122 in accordance with DIN17440, material no. 1.4401. or ASTM A276/A479 type 316.
  • Brass Fitting: CuZn35Ni2 in accordance with DIN17660/17672, material no. 2.0540.
  • Elastomer Seal: NBR(BUNA-N), DIN 17660FPM (VITON).
    •
